OPTIVIS 0.3MP VGA USB2.0 Camera

The OVT-7251B is a compact high-performance VGA USB camera module designed for embedded vision applications. Built around the 1/7.5-inch OV07251 CMOS sensor with global shutter, it delivers clear, stable imaging at a maximum resolution of 640×480 pixels. Supporting both MJPEG and YUY2 output formats, it achieves up to 100FPS at 640×480 in MJPEG mode, ideal for fast‑motion capture.

This module features a 67° field of view, fixed/manual focus, and full UVC compliance for plug-and-play operation across Windows, Android, Linux, and Mac OS. It offers adjustable parameters including brightness, contrast, saturation, hue, sharpness, gamma, white balance, backlight contrast, and exposure.

With a tiny 28×28mm form factor, 5V DC power input, 70mA working current, and an operating temperature range of -20°C to 60°C, the module is reliable for industrial, IoT, and consumer electronics integration. It uses a 5PIN 1.25mm connector and comes with a 1.0-meter USB cable, supporting high‑speed USB2.0 transmission.
