OPTIVIS 1MP HDRUltra-slim USB2.0 Camera

The OVT-JX62B is a slim, high-performance 1-megapixel USB camera module built for embedded vision, industrial, and smart device applications. It features a 1/4-inch JX-H62 CMOS sensor with electronic rolling shutter, delivering sharp 1280×720 HD video with up to 72dB dynamic range for clear imaging in varied lighting.

Supporting both MJPEG and YUY2 output formats, this module runs at 30FPS in 720P under MJPEG and offers flexible frame rates across lower resolutions. It provides a choice of 120°or 140° ultra-wide field of view, with fixed or manual focus to suit different installation needs.

Fully UVC compliant and plug-and-play ready, it works seamlessly with Windows, Android, Linux, and Mac OS without extra drivers. Users can adjust brightness, contrast, saturation, hue, sharpness, gamma, white balance, backlight compensation, and exposure for optimized visuals.

Measuring only 60×8mm and powered by 5V DC (120mA working current), this ultra-slim module fits space constrained designs. It operates reliably from -20°C to 60°C and uses a 5-pin 1.0mm connector with a standard 1-meter USB cable for easy integration.
